Description
ORCA 800 SERIES 80A WATERPROOF BRUSHED ESC W/Tamiya battery/motor plugs fitted and Program Card.
Online Manual
Features
Brushed System
Water Proof
Alum Case
LED Program Card included
Multiple Adjustable Parameters
BEC : 3A 6V
Peak Current 400A
Continuous Current 80A
Motor Type: Brushed 540 size Motor
Voltage input : DC 6V - 12.6V (Lipo 2-3Cells)
Dimensions: 29(L) x 34.8(W) x 10.2(H) mm
Weight: 20g excluding wires
Includes:
ORCA 800 Series 80A Waterproof Brushed ESC (1 pc)
LED Program card
Setup Parameter:
Running Mode: Fwd/Bke/Rev, Fwd/Bke, Fwd/Rev
Battery tpe: LiPo / LiFe / Nixx
Battery Cutoff
Initial Launch Force
Punch
PWM: 1k, 4k, 8k, 12k, 16k, 24kHz
Throttle Compress
Initial Start Force
Max Forward Force
Max Reverse Force
Max Brake Force
Brake Punch
Drag Brake
Initial Brake Force
Neutral Range
Suitable for Touring Car, Vintage, Tamiya, Crawlers, Racing, TT-01, TT-01, Pre 89 Vintage Class or Pre 98 Vintage
Note. This ESC is not compatible with other ORCA program cards.
